China Professional UV LED Manufacturer | Custom Wavelength 365-405nm | 2-Year Warranty
| UV wavelength | Application scenarios | Buyer perception |
| 365nm | Transparent adhesive, optical components, replacement of old formula mercury lamps | Good penetration, high-end quality |
| 385nm | Industrial ink/coating transition plan | Strong compatibility |
| 395nm | UV printing, glue, universal curing | Most commonly used, high efficient |
| 405nm | Photosensitive resin/Near Visible | Cost friendly |
Notice:Wattage is not cure power. We match irradiance (W/cm²), working distance and photoinitiator — not just “50W/100W”. | ||
Establish in 2016,Dongguan Wale Electronics Co., Ltd is a manufacturer specialized in the research,development and production of high power led,UV led,UVC led,IR led and led grow light,we have different wavelengths from 255nm to 1550nm, hot selling lots of LEDs in wavelength such as 265nm,280nm,365nm,395nm,405nm,630nm,660nm,740nm,790nm,808nm,830nm,850nm,940nm,980nm,etc, can produce different power from 0.5w to 1500w.
We have CE and Rohs certification,all of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
We promise all of our products are 100% quality test before sent out,OEM and ODM service are available,our engineer team can provide professional service to support your project.
Items | Value |
Power | 50w/100w |
Peak wavelength | 365nm,375nm,385nm,395nm,405nm |
Forward current | 1500/3500mA |
Forward voltage | 30-36V |
Output radiant | 50000-60000mW |
LED plate materials | Copper |
Beam angle | 120-140 degrees |
Application | UV printer,Curing,Detection,Archaeology, plants grow lights,etc |
Other options | 1w-600w,375nm,385nm,395nm,405nm, 420nm,430nm,etc (255nm-1650nm is available) |
Q1: Can you accept the sample order?
Yes, we can. we welcome sample order to test and check quality.
Q2: What wavelength UV LED for UV glue curing?
We suggest you to use 395nm for UV glue curing.
Q3: How to choose between 365nm 385nm 395nm?
365nm is mainly used for fluorescence detection, UV curing,it's high cost while compared with others.
385nm is mainly used for UV curing,PCB glue curing,it has lower cost and Heat dissipation while compared with 365nm.
395nm is mainly used for UV curing(UV printer),mosquito attraction, stage light, consumer electronics,it's the most bright and cheap.
If you are not sure which one is suitable for you, we can sell some samples for you to test first.
Q4: How long do UV LEDs last?
Usually it's 50000 hours, it's affected by heat dissipation performance,its lifespan will be longer if better heat dissipation performance.
Q5: What's your warranty?
Our goods have 2 years warranty and about 50000 hours lifespan,
We accept return if quality problem during warranty.
Q6: Why choose us?
1) We provide factory-direct prices.
2) We have our own R&D team, the products can be customized according to your requirements.
3) We provide superior and timely pre-sales advice and after-sales service.
4) We provide service door to door (China to your warehouse), much easy transaction.
